EDHK4-6

Output tooth profile: 32 teeth; Stall torque: 12Nm; SOP Time: September 2018; Applicable models: Changan C211 left front anti-pinch, S202 left front anti-pinch.

Category:

Automobile window rolling motor series

Product Description

Item	Connector	Motor housing	Motor	EMC	Idle Current(max.)	Idle speed	Stall torque	Noise （DC12V@30 cm）	Stall Current(max.)	Motor weight(max.)
unit		mm	mm	level/CISPR 25	A	rpm	Nm	dB	A	g
1	2pin/6pin/A P	70.3	156/167	3	2.5	70-110	5.6-10.0	53	25	430/460/500
2	2pin/6pin/A P	77.3	163/174	3	2.5	70-110	8.0-12.0	53	28	430/460/500
